Universal M15012-27CK-5EU-J

Description

Universal Lighting Technologies Code 188639.05 M1501227CK5EUJ 150 Watt 120-277V Metal Halide Electronic J Stud Mount Ballast (1) 150W Ceramic Metal Halide Lamp Ansi Code C102,C142, M102,M142 Voltage : 120-277V  +/-10%, 50/60Hz Resonance Start Active power factor correction Microprocessor controlled EOL Protection DIM: (L) 5.51in (W) 3.62in x (H) 1.57in (J) Stub mount (bottom lead exit) Universal Order Code 188638.05 5-Lead Wires (Black, White, Green,Blue, Red) RoHS Compliant Spec Sheet Additional Information Energy Efficient Greater than 20% increase in efficiency Lowers lighting operation costs Full Light Output Provides same light levels as magnetic ballasts being replaced  Quiet Operation Significantly quieter than magnetic ballasts  High Frequency Operation No lamp flickering  Light Weight – Low Profile Case Simplifies transportation & installation Less interference with ballast channel cover during replacement Slimline Ballasts Feature Parallel Lamp Operation When one lamp fails, other lamp remains lit Instant start electronic ballast for long lamp starting cycles and low initial cost RoHs Compliant UL Type 1 Outdoor
