Universal B432IUNVHP-A

Description

Universal Lighting Technologies B432IUNVHPA 4-Lamp F32T8 120-277V 50/60hz Electronic Instant Start Ballast Operates the Following Lamp Types (3-4) F17T8/ECO 24in Fluorescent Lamp (3-4) F25T8/ECO 36in Fluorescent Lamp (3-4) F32T8/25W 48in Energy Saving F32T8 25W Lamps (3-4) F28T8/28W 48in Energy Saving F32T8 28W Lamps (3-4) F32T8/WM 48in Energy Saving F32T8 30W Lamps (3-4) F32T8 (48in FO32/ECO 32W Standard Lamps) (3) FO40 60in Fluorescent T8 Lamp (4) F25T12 36in Fluorescent T12 Lamp Also Suitable For Equivalent U-Bend Fluorescent T8 Lamps   Additional Information: Universal Lighting Technology Triad B432IUNVHP-A000I Parallel Instant Start High Performance low profile ballasts with THD<10% offer the convenience of universal input voltage (108 - 305 volts) ensuring you have the right voltage ballast, and a low profile design for greater flexibility in light fixture design.Will easily retrofit any T12 into a T8 fixture Also it's UL Listed for wet or damp locations & approved by the NEMA Premium Electronic Ballast program   Product Details High performance electronic ballast for all general fluorescent applications Instant start electronic ballast for long lamp starting cycles and low initial cost Multi-Voltage Technology handles voltage from 120 to 277V Light-weight, Low Profile Housing (Dim:9.5”L x 1.7”W x 1.18”H) Parallel Circuitry: keeps remaining lamps lit if one or more go out Line Voltage: 108vac - 305vac, 50/60Hz Manufactured in North America  Meets ANSI Standard C82.11-1993 Normal Ballast Factor < 10% THD Sound Rating A (20-24 decibels) Parallel Instant Start RoHs Compliant UL Type 1 Outdoor
