Description
Universal 22W M175 J-Mount 120V Electronic Metal Halide Ballast (1) 22W Ceramic Metal Halide Lamp Ansi Code M175/C175 Voltage : 120V, +/-10%, 50/60Hz Microprocessor controlled Meets ANSI Standard C82.14-2006 Meets ANSI Standard C62.41-1991 DIM: (L) 2.99in (W) 1.3in x (H)1.1in J-Mount for tracklight Bottom lead exit 5-Lead Wires( Black, White, Green,Blue, Red RoHS Compliant Spec Sheet Additional Information Energy Efficient Greater than 20% increase in efficiency Lowers lighting operation costs Full Light Output Provides same light levels as magnetic ballasts being replaced Quiet Operation Significantly quieter than magnetic ballasts High Frequency Operation No lamp flickering Light Weight – Low Profile Case Simplifies transportation & installation Less interference with ballast channel cover during replacement Slimline Ballasts Feature Parallel Lamp Operation When one lamp fails, other lamp remains lit Instant start electronic ballast for long lamp starting cycles and low initial cost RoHs Compliant UL Type 1 Outdoor
