Description
Universal 20W Metal Halide M156 1-Lamp Electronic 120V Mini Square Case Ballast Operates the Following Fluorescent Lamps: (1) 20W Ceramic Metal Halide Lamp Ansi Code M156/C156 Voltage : 120V, +/-10%, 50/60Hz Microprocessor controlled DIM: (L) 3.74in (W) 2.98in x (H) 1.21in Feet mount (Side lead exit) Universal Order Code 188151 5-Lead Wires( Black, White, Green,Blue, Red) RoHS Compliant Spec Sheet Additional Information Energy Efficient Greater than 20% increase in efficiency Lowers lighting operation costs Full Light Output Provides same light levels as magnetic ballasts being replaced Quiet Operation Significantly quieter than magnetic ballasts High Frequency Operation No lamp flickering Light Weight – Low Profile Case Simplifies transportation & installation Less interference with ballast channel cover during replacement Slimline Ballasts Feature Parallel Lamp Operation When one lamp fails, other lamp remains lit Instant start electronic ballast for long lamp starting cycles and low initial cost RoHs Compliant UL Type 1 Outdoor Cross Reference Aromat M2012CK-6EU-F Vossloh Schwabe M2012CK-6EU-F
